2800KG Bead Breaker
PLC-602ADL Professional Leverless Duel Speed Tyre Changer
Finance or Capricorn payments available
Overview
This tilt-back tyre changer with assisting arm is designed for efficient tyre mounting and demounting, including RSC and run-flat tyres. It features a 20 mm cylinder with variable torque adjustment for the bead breaker, together with a 2800 kg bead breaking force for separating tyres from rims.
The machine uses a 55 mm horizontal shaft with a lengthened hex bar sleeve for increased strength, while the double-bending column is constructed from 5 mm steel plate for added rigidity. The included AI390H assist arm uses a tyre pressing block to support rim centring and tyre handling.
With three-position tyre pressing, a leverless bar system and dual-speed turntable rotation, the machine is designed to improve efficiency during mounting and demounting operations.
Features
- Tilt back column with assisting arm
- Standardly equipped with 20mm cylinder along with variable torque adjustment bead breaker force, suitable for each RSC tyres and run-flat tyres.
- Adopted diameter 55mm horizontal shaft. the lengthened hex bar sleeve makes the machine more robust.
- Double-bending column is made of steel plate with 5mm thickness which assures high intensity, no deformation, protect tyres and rims safe.
- Equipped with Al390H assist arm which adopted tyre pressing block
- The machine adopts the parkerising bead breaker cylinder having bead break power 2800KG to bead break the tire from rim easily.
- Standardly equipped with the assist arm which adopted tyre pressing block for the rim centring, easy and convenient operation.
- Three positions pressing the tyres to ensure high efficiency in mounting and demounting process.
- Leverless bar system
- Tyre lifter optional
Specification
- Outside Clamp: 11-24＂
- Rim Width: 3-14＂
- Inside Clamp: 13-26＂
- Max Wheel Diameter: 1100 mm
- Working air pressure: 8-10bar
- Bead breaking force: 2800kg
- Turntable Rotation Dual Speed: 6.5/13rpm
- Power Supply Voltage: 220V/380V
- Motor Power: 0.75/1.1 kw
- Noise: ＜70dB
- Packages quantity: 2
- Packages dimensions: Main unit: 1420 x 1000 x 1100mm, Assisting arm: 1650 x 500 x 580mm
- Packages weights: Main unit: 350kg, Assisting arm: 120kg
